Syntec System Gantry Heavy Duty 5 Axis CNC Machining Center 5 Spindles Large Work Station High Accuracy Multifunctional

Syntec System Gantry Heavy Duty 5 Axis CNC Machining Center 5 Spindles Large Work Station High Accuracy Multifunctional
  • Syntec System Gantry Heavy Duty 5 Axis CNC Machining Center 5 Spindles Large Work Station High Accuracy Multifunctional

    • Syntec System Gantry Heavy Duty 5 Axis CNC Machining Center 5 Spindles Large Work Station High Accuracy Multifunctional

    Request a Quote
    typeGantrytable travel (x) (mm)3000
    table travel (y) (mm)1400table travel (z) (mm)700
    repeatability (x/y/z) (mm)±0.05positioning accuracy±0.02
    spindle taperHSK63Fno. of spindles5
    tool magazine capacityNonecnc control systemChina Taiwan Syntec
    machining capacityHeavy Dutyvoltagecustomize
    table size2500mm*1300mm*2machinery test reportProvided
    video outgoing-inspectionProvidedmin. time of tool change(s)None
    key selling pointsHigh-Accuracy, Multifunctional, High Productivityweight (t)8
    max. table load(kg)1000dimension(l*w*h)7500x2250*4200mm(295.28x88.58*165.35in)
    range of spindle speed0 - 18000rapid feed speed0 - 5000
    Spindle MotorDual Spindle 9KW x 2pcs (18000rmp)X/Y/Z axis stroke3000/2*1400*150mm
    Gantry Height700mmPositioning Accuracy+-0.05mm
    Total Power32KWWork Table2500mm*1300mm*2pcs
    Driving ModeServo MotorsInverterFolinn 11KW x 2pcs
    Vacuum PumpEurovac Dry Vacuum Pump 7.5kw x 2pcsElectrica /Pneumatic partsFrench Schineider/China Taiwan Airtac
