MZB42 Double Row Multiple Drilling Machine

MZB42 Double Row Multiple Drilling Machine
  • MZB42 Double Row Multiple Drilling Machine

    • MZB42 Double Row Multiple Drilling Machine

    Request a Quote
    max. drilling dia. (mm)35typeDrilling & Milling Machine
    voltage380V+zero linecnc or notNormal
    machinery test reportProvidedcore componentsMotor
    video outgoing-inspectionProvidedkey selling pointsHigh-Accuracy
    range of spindle speed(r.p.m)2800 - 2840 r.p.mpower (kw)1.5
    weight (kg)550drilling speed2840r/min
    dimension(l*w*h)1100*1300*1700mm(43.31*51.18*66.93in)After-sales Service ProvidedEngineers available to service machinery overseas
    max. diamerter of holes35mmdepth of drilled holes0-60mm
    number of spindles42max. dimensions of piece to be drilled2500*920*70mm
    rotation of spindle2840r/minair pressure0.5-0.8mpa
    hight of working platform800mmTotal power4.5kw
    Distance between center of spindles32mm
