XH7126 CNC Small Vertical Machining Center XH 7126 3 Axis Micro Machining Center

XH7126 CNC Small Vertical Machining Center XH 7126 3 Axis Micro Machining Center
  • XH7126 CNC Small Vertical Machining Center XH 7126 3 Axis Micro Machining Center

    • XH7126 CNC Small Vertical Machining Center XH 7126 3 Axis Micro Machining Center

    Request a Quote
    typeVERTICALnumber of axes3
    table travel (x) (mm)450 mm(17.72in)table travel (y) (mm)320 mm(12.60in)
    table travel (z) (mm)400 mm(15.75in)repeatability (x/y/z) (mm)±0.005
    positioning accuracy±0.015spindle taperBT40
    no. of spindlesSingletool magazine capacity12
    cnc control systemSiemensvoltage220/380V
    table size450/320/400mmmachinery test reportProvided
    video outgoing-inspectionProvidedmin. time of tool change(s)2
    key selling pointsAutomaticweight (t)2.4 T(2.65short tons )
    max. table load(kg)300 kg(661.39lb)dimension(l*w*h)2200*1900*2200mm(86.61*74.80*86.61in)
    range of spindle speed1 - 6000 r.p.mspindle motor power3.7
    Siemens 808D CNC systemFoundation gasket and adjusting boltBt40-120-6000rpm belt spindleElectrical cabinet cold and heat exchanger
    Machine tool lighting working lampCentralized automatic feed lubrication systemSpindles clean the airTricolor warning light
    Chip liquid systemSeparate handwheel10.4 "displayThree ball type linear guide rail
    Servo transformer3-axis precision grinding ball screwSpindle taper: BT40Metal CNC Vertical Machining Center
    RS232 interface5.5/7.5KW machine center(Alternating current servo)3.7kWRandom technical document
