Professional manufacturer of woodworking machinery
Cabinet Furniture Industry Wood MDF Processing CNC Router Nesting Machine 1325 Straight Row Tool Change Machining Center 1530
Cabinet Furniture Industry Wood MDF Processing CNC Router Nesting Machine 1325 Straight Row Tool Change Machining Center 1530
| Working Table Size(mm) | 2000X3000 | number of axes | 5 |
| voltage | AC380V/50HZ | machine type | CNC Router |
| No. of Spindles | Multi | key selling points | Competitive Price |
| core components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox | cnc or not | CNC |
| video outgoing-inspection | Provided | machinery test report | Provided |
| Power (kW) | 10 | weight (kg) | 3500 |
| range of spindle speed(r.p.m) | 1 - 24000 rpm | positioning accuracy (mm) | 0.03 |
| travel (x axis)(mm) | 2000 | travel (y axis)(mm) | 3000 |
| repeatability (x/y/z) (mm) | 0.03 | Spindle Motor Power (kw) | 10 |
| dimension(l*w*h) | 3250*2250*2000mm(127.95*88.58*78.74in) | Working area | 2000mm*3000mm*200mm |
| Color | white(any color u want) | Working Voltage: | AC380V/50HZ |
| Drive and Motor: | Stepper/Servo | Spindle: | Water Cooling SpindleAC Servo motors from Germany |
| Application: | Cutting | Software: | Artcam |
| Spindle power: | 10kw | After-sales Service Provided | Engineers available to service machinery overseas |
| Transmission: | Rack and pinion |
