5 Axis CNC Vertical Machining Center VMC650
5 Axis CNC Vertical Machining Center VMC650
| type | VERTICAL | table travel (x) (mm) | 650 |
| table travel (y) (mm) | 400 | table travel (z) (mm) | 500 |
| repeatability (x/y/z) (mm) | ±0.005 | positioning accuracy | ±0.0075 |
| spindle taper | BT40 | no. of spindles | Single |
| tool magazine capacity | 24 | cnc control system | KND |
| machining capacity | Light Duty | voltage | 220V/380V/410V |
| table size | 920x400 | machinery test report | Provided |
| video outgoing-inspection | Provided | min. time of tool change(s) | 3 |
| key selling points | High Productivity | weight (t) | 4000 KG |
| max. table load(kg) | 400 kg(881.85lb) | dimension(l*w*h) | 2300*1950*2450mm(90.55*76.77*96.46in) |
| range of spindle speed | 0 - 10000 r.p.m | rapid feed speed | 1 - 8000 mm/min(0.04-314.96in/min) |
| Product name | cnc 5 axis machining center VMC850 china cnc machining centers | Machine Type | CNC Vertical Machining Center |
| Precision | High Precision Machining Center | CNC Controller | KND/GSK/FANUC/SIEMENS |
| Model | VMC 650 | Color | Cusomer Request |
| Spindle Speed | 8000rpm/10000rpm | Table size | 920*400mm |
| Motor | 5.5/7.5KW | Spindle taper | BT40/BT50 |
