4 Axis Automatic CNC Machine ATC Wood Carving CNC Router Milling Machine Furniture Making Lathe Machine for Metal
4 Axis Automatic CNC Machine ATC Wood Carving CNC Router Milling Machine Furniture Making Lathe Machine for Metal
| type | VERTICAL | number of axes | 4 |
| voltage | 3Phase 220V 380V | table travel (x) (mm) | 800 mm(31.50in) |
| table travel (y) (mm) | 500 | table travel (z) (mm) | 500 |
| positioning accuracy | ±0.015 | repeatability (x/y/z) (mm) | 0.01 |
| spindle taper | BT40 | cnc control system | NEWker |
| machining capacity | Medium Duty | no. of spindles | Single |
| machinery test report | Provided | video outgoing-inspection | Provided |
| key selling points | High-Accuracy | max. table load(kg) | 50 |
| range of spindle speed | 20 - 8000 | dimension(l*w*h) | 2700*1800*2200 |
| weight | 3200 | Machine Type | Machining Center |
| Product name | NEWKer | Model | CNC-950QM |
| Precision | ±0.015 | CNC Controller | NEWKer |
| Axis | 2-6 Axis | Marketing Type | Ordinary Product |
| Warranty of core components | 1 Year |
