Whole House Customization LUDO Machining Center Straight Row Tool Changer CNC Router ATC Furniture Cutter Machinery
Whole House Customization LUDO Machining Center Straight Row Tool Changer CNC Router ATC Furniture Cutter Machinery
| number of axes | 3 | voltage | AC380V/50HZ, 3PH |
| machine type | CNC Router | No. of Spindles | Double |
| key selling points | Easy To Operate | core components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox |
| cnc or not | CNC | video outgoing-inspection | Provided |
| machinery test report | Provided | weight (kg) | 1500 |
| range of spindle speed(r.p.m) | 1 - 24000 rpm | positioning accuracy (mm) | 0.03 |
| travel (x axis)(mm) | 1300 | travel (y axis)(mm) | 2500 |
| repeatability (x/y/z) (mm) | 0.03 | Spindle Motor Power (kw) | 3 |
| dimension(l*w*h) | 3200*2150*1850mm(125.98*84.65*72.83in) | Item | 1325 cnc router |
| color | can customize | Working Area | 1300*2500*200mm |
| Spindle power | 3.5KW air cooling spindle ( Water for choose ) | Inverter | 3.7KW Delta or Fuling Inverter |
| Drive and Motor | Stepper and Sever motors and drivers | Transmission | XY-axis:rack and gear Z-axis:ball screw |
| Controller | DSP,NC STUDIO | Software | Artcam/Type3 |
| Guild Rail | Taiwan HIWIN Square Linear Rail |
