VMC8070 VMC CNC Milling 3 Axis Metal Lathe Vertical Machining Center

VMC8070 VMC CNC Milling 3 Axis Metal Lathe Vertical Machining Center
  • VMC8070 VMC CNC Milling 3 Axis Metal Lathe Vertical Machining Center

    • VMC8070 VMC CNC Milling 3 Axis Metal Lathe Vertical Machining Center

    Request a Quote
    typeVERTICALnumber of axes4
    voltage380Vtable travel (x) (mm)800
    table travel (y) (mm)700table travel (z) (mm)380
    positioning accuracy±0.01repeatability (x/y/z) (mm)±0.005
    spindle taperER32cnc control systemSyntec/Fanuc/Siemens/Mitsubishi
    machining capacityMedium Dutyno. of spindlesSingle
    machinery test reportProvidedvideo outgoing-inspectionProvided
    key selling pointsHigh-Accuracyspindle motor power(kw)8
    max. table load(kg)800 kg(1763.70lb)range of spindle speed100 - 18000
    dimension(l*w*h)2450*2030*2460mm(96.46*79.92*96.85in)weight4600
    Machine nameCNC Milling MachineMachine TypeDouble Column
    Worktable size800*700mmX/Y/Z axis travel800/700/300mm
    X/Y/Z axis motor power1300/1300/1300wGantry width900mm
    Beam to worktable550mmSpindleEr32/8kw/15000rpm
    Spindle nose to worktable170-340mmControllerSyntec/Fanuc/Siemens/Mitsubishi
