TE140 Heavy Duty Horizontal CNC Lathe 1420mm Max Swing Over Bed High Precision CNC Turning Lathe

TE140 Heavy Duty Horizontal CNC Lathe 1420mm Max Swing Over Bed High Precision CNC Turning Lathe
  • TE140 Heavy Duty Horizontal CNC Lathe 1420mm Max Swing Over Bed High Precision CNC Turning Lathe

    • TE140 Heavy Duty Horizontal CNC Lathe 1420mm Max Swing Over Bed High Precision CNC Turning Lathe

    Request a Quote
    typeHorizontal Flat Bed CNC Lathemax. length of workpiece (mm)1500, 3000, 5000, 6000, 8000
    positioning accuracy (mm)±0.02repeatability (x/y/z) (mm)X:±0.009/Z:±0.01
    number of axes2cnc control systemGSK/SIEMENS/FANUC (Optional)
    no. of spindlesSingletool post stations4, 8, 12
    machining capacityMedium Dutyvoltage380 V, 220 V, 110 V
    machinery test reportProvidedvideo outgoing-inspectionProvided
    key selling pointsHigh Rigidity, 1420mm Max Swing, Heavy Duty CNC Lmax. weight of workpiece(kg)10000
    travel (x axis)(mm)720travel (z axis)(mm)5100
    width of bed (mm)850dimension(l*w*h)4650/6200/8200/9200/11200*1460*1635
    weight18500range of spindle speed1 - 500
    cutting torque18700
