Factory Direct Vertical Twin Spindle Heavy Duty Automatic CNC Lathe Machine FANUC for Large Turning Center
Factory Direct Vertical Twin Spindle Heavy Duty Automatic CNC Lathe Machine FANUC for Large Turning Center
| type | VERTICAL | max. length of workpiece (mm) | 1400 |
| positioning accuracy (mm) | ±0.003 | repeatability (x/y/z) (mm) | ±0.003 |
| number of axes | 2 | cnc control system | FANUC |
| no. of spindles | Twin | tool post stations | 12, 8, 6, 4 |
| machining capacity | Heavy Duty | voltage | 380 V, 220 V |
| machinery test report | Provided | video outgoing-inspection | Provided |
| key selling points | Multifunctional, Automatic, Competitive Price, High Safety Level, High-Accuracy, High Productivity, High Rigidity | max. weight of workpiece(kg) | 1000 |
| travel (x axis)(mm) | 680 | travel (z axis)(mm) | 380 |
| width of bed (mm) | 300 | dimension(l*w*h) | 1950*1500*1650 |
| weight | 1600 | range of spindle speed | 50 - 3000 |
| cutting torque | 154 | Product name | Factory Direct Premium Quality Vertical Twin Spindle Heavy Duty |
| Spindle Drive | A-type V-belt (3 belts) or synchronous belt (optional) | X-Axis Guide | Type 30 Roller Linear Guide (Mason) or German Rexroth (optional) |
| Z-Axis Guide | Type 35 Roller Linear Guide, Z-axis span 300mm | Rapid Traverse | Maximum 30 m/min |
| Clamping | Hydraulic chuck clamping (pneumatic optional) | Alarm | Three-color alarm light |
| Rotary Cylinder | Hollow TK1248 (latest through-type) | Bed | 35-degree integral casting, semi-enclosed stainless steel sheet metal |
| Footprint | Integral casting, chip ejection on the right and rear sides |
